RYZ Series Fireproof Intumescent Seal

For gun safes: The RYZW seal, made of a graphite-based intumescent strip inside and a PVC hard shell outside, expands 20-30 times during a fire to seal gaps between the gun safe door and frame, preventing flames, heat, and smoke from entering. Installation involves cleaning the surface, measuring and cutting the seal, and pressing it firmly into place with its strong self-adhesive backing.

For fire doors: The seal expands 20-30 times at high temperatures to effectively seal door gaps, blocking flames, heat, and smoke. Installation requires cleaning the door edges, cutting the seal to size, and firmly adhering it to the door edges. Both applications are water and humidity resistant, easy to install, and provide reliable fire protection.

Send Inquiry

Functions of RYZ Fireproof Intumescent Seal on Safes

  1. Fire Resistance: In the event of a fire, the seal rapidly expands to form a dense barrier, preventing flames from entering the safe.
  2. Smoke Blocking: The expanded seal effectively closes gaps, preventing toxic smoke from infiltrating and protecting items inside from contamination.

  3. Heat Insulation: The expanded layer of the seal blocks high temperatures, reducing the internal temperature of the safe and preventing damage to valuables caused by heat.

  4. Enhanced Sealing: During daily use, the seal improves the airtightness of the safe, providing protection against dust and moisture and extending its lifespan.

  5. Property Protection: Offers reliable fire protection for documents and valuables inside the safe, minimizing fire-related losses.

Product CodeT*W (mm)Product CodeT*W (mm)
RYZW28152.8*15RYZW30153.2*15
RYZW30103.2*10RYZW30203.2*20

Functions of RYZ Fireproof Intumescent Seal on Fire Doors

  1. Preventing Fire Spread: During a fire, the seal rapidly expands to close gaps, preventing flames from spreading to other areas through the door seams.
  2. Blocking Smoke and Toxic Gases: The expanded seal effectively blocks smoke and harmful gases, buying time for evacuation.

  3. Heat Insulation: The expanded layer of the seal blocks high temperatures, reducing the door’s surface temperature and delaying fire damage to the door.

  4. Improving Fire Door Performance: Enhances the overall fire resistance of fire doors, ensuring they meet required fire rating standards.

  5. Life Safety Protection: Provides a reliable fire barrier for building occupants, ensuring the safety of escape routes and reducing fire-related casualties.

Product CodeT*W (mm)Product CodeT*W (mm)
RYZW40104*10RYZW60106*10
RYZW40154*15RYZW60156*15
RYZW40204*20RYZW60206*20
RYZW40254*25RYZW60256*25
RYZW40304*30RYZW60306*30
RYZW40384*38RYZW60406*40

Functions of RYZS Fireproof Intumescent Seal

  1. Daily Protection:The brush design effectively blocks dust and insects, keeping door gaps clean and maintaining the door’s appearance and functionality.
  2. Fire Safety:In case of fire, the sealing strip will expand 20-30 times in a rapid manner, thus blocking the gaps, blocking flames and smoke, providing thermal insulation to slow down the spread of fire, and improving the overall performance of the fire door.
Product CodeT*W (mm)Product CodeT*W (mm)
RYZWS40104*10RYZWS60106*10
RYZWS40154*15RYZWS60156*15
RYZWS40204*20RYZWS60206*20
RYZWS40254*25RYZWS60256*25
RYZWS40304*30RYZWS60306*30
RYZWS40384*38RYZWS60406*40

Functions of RYZP Fireproof Intumescent Seal

  1. Daily Protection:The brush design effectively blocks dust and insects, keeping door gaps clean and maintaining the door’s appearance and functionality.
  2. Fire Safety:In case of fire, the sealing strip will expand 20-30 times in a rapid manner, thus blocking the gaps, blocking flames and smoke, providing thermal insulation to slow down the spread of fire, and improving the overall performance of the fire door.
Product CodeT*W (mm)Product CodeT*W (mm)
RYZWP40104*10RYZWP60106*10
RYZWP40154*15RYZWP60156*15
RYZWP40204*20RYZWP60206*20
RYZWP40254*25RYZWP60256*25
RYZWP40304*30RYZWP60306*30
RYZWP40384*38RYZWP60406*40

Functions of RYZP Fireproof Intumescent Seal

  1. Daily Protection:The brush design effectively blocks dust and insects, keeping door gaps clean and maintaining the door’s appearance and functionality.
  2. Fire Safety:In case of fire, the sealing strip will expand 20-30 times in a rapid manner, thus blocking the gaps, blocking flames and smoke, providing thermal insulation to slow down the spread of fire, and improving the overall performance of the fire door.
Product CodeT*W (mm)Product CodeT*W (mm)
RYZWP40104*10RYZWP60106*10
RYZWP40154*15RYZWP60156*15
RYZWP40204*20RYZWP60206*20
RYZWP40254*25RYZWP60256*25
RYZWP40304*30RYZWP60306*30
RYZWP40384*38RYZWP60406*40

RYZ series fireproof intumescent seals are tested at high temperatures

The RYZ series of fire-resistant intumescent seals undergo rigorous high-temperature testing to ensure their reliability and performance under fire conditions.

The test simulates a real fire high temperature environment to verify the expansion rate, sealing effect and fire resistance of the seal under high temperature.

Get Your Custom Intumescent Fire Door Strips

RESSA is a trusted supplier of full range of intumescent fire door strips, with years of experience in creating high-quality fire protection solutions. It specializes in manufacturing high-quality custom fire door seals and gaskets to cover various need of customers. Here are your custom selections:

Get A free quote

Features that Make Our Intumescent Fire Door Strips Unique

expanding RESSA RPB Series Intumesent Fire Strips

Advanced Expansion Technology

RESSA intumescent fire door strips are engineered with a proprietary heat-activated expansion process that ensures rapid and uniform swelling of seals in fire, creating an impenetrable barrier against fire and smoke.

Superior Self Adhesive Performance

Surface mounted fire door strips equipped with industrial-grade adhesive, our strips self adhere firmly to a variety of surfaces, ensuring a long-lasting seal that won’t degrade over time or under extreme temperatures.

intumescent -RESSA RPB Series Fire door strips

Multi-Functional Sealing Performance

Beyond fire door insulation, some our intumescent fire door strips also offer excellent waterproof property, smoke prevent property, acoustic insulation and thermal properties, adding additional value to the installation.

BS476 Test RESSA RPB Series Intumesent Fire Strips

Tested Prooved and Certified Quality

Our products pass the testing of fire doors integrity and insulation test according to the BS476 test standard and have received certification from recognized safety standards organizations, assuring their effectiveness and reliability.

Manufacturing Process of Intumescent Fire Door Strips

  1. Raw Material Preparation: Gather materials including different kinds of fireproof intumescent materials, self adhesive, additives… ensure material expand to meet quality standards of fire doors requirement.
  2. Mixing: Mix the raw materials according to the formula and prepare them under specific temperature and humidity conditions. This may involve blending the expanding materials with other additives to achieve the desired physical and chemical properties.
  3. Extrusion or Calendering: Use an extrusion machine or pressing machine or inserting machine to shape the mixed intumescent materials, forming the initial shape of the intermittent strips.
  4. Cutting and Shaping: Cut the intermission strips to the specific dimensions and shapes. Precise molding may be achieved using molds or cutting tools.
  5. Quality Testing: Perform quality tests, including dimension checks, expansion performance, fire resistance, etc.for intumescent gasket.
  6. Packaging and Dispatch:Package the qualified intumescent strips and prepare them for dispatch to the market.
GET A FREE QUOTE
Intumescent strips production process

Our Certificates in Intumescent Fire Door Strips

RESSA Test certificate (4)
RESSA Test certificate (5)
RESSA Test certificate (6)
RESSA Test certificate (1)

Ready to Get the Perfect Fire Door Strips?

Contact Us to Get A Free Consultation

Fire Door Strips FAQs

Fire Door Strips are specialized seals installed on fire doors to prevent the passage of smoke, flames, and toxic gases during a fire, enhancing the door’s ability to compartmentalize and contain the spread of fire.

Over-painting of fire door strips should not compromise performance in a fire situation – however, do not suggest paint over fire door strips as this will certainly compromise the sealing containment performance and use life. If the intumescent strips on fire doors has already been painted over, you will need to replace it. Our seals are available in a range of colours, plus woodgrain and metallic finishes, so over-painting should not be necessary.

In the event of a serious fire, fire doors are one of the most important components in ensuring safe exit, containing the fire and saving lives. But they can be rendered useless by not using the correct components including intumescent strip. Gaps around the four sides of a fire door leaf are essential, it is the only way the door can open and close. But these gaps create a point of weakness, where fire can take hold and destroy the door, and toxic and smoke can pass through. RESSA intumescent strip works by sealing around the edges and gaps of a fire door and door frames in the event of a fire.

In essence, all intumescent do the same job, but not necessarily in the same way. You’ll need to know which specifications you require; consult our technical team to discuss this area in depth at sales@ressatech.com.

Yes, RPB Series flexible fire door strips are suitable for both new builds and for retrofitting into existing structures, providing an effective fire-stopping solution. The intallation method is very easy by self-adhesive.
